Makine Parkuru
Cutting Machinery
CNC-PLASMA CUTTiNG MACHiNE
(Ajan Elektronik Makina)
Plate and Tube cutting
3000 mm x 12000 mm & Ø600 mm x 12000 mm capacity
Max. plate thickness cutting 200 mm
Max. tube thickness cutting 40 mm
Mild steel, stainless steel and aluminium cutting
Production year: 2022
FiBERMAK SM 10000 fiber optic laser cutting machine (Ermaksan)
Plate cutting
4-axis
16000*3000 mm capacity
Max. plate thickness cutting 30 mm
Mild steel, stainless steel and aluminium cutting
Production year: 2023
Bandsawing machine
(Akva Makine)
Material cutting
Capacity diameter 550 mm
Blade dimension 41x1.3x6,780mm
Blade motor 4kW(5.36hp)
Max.Power 8.96kW(12 hp)
Production year: 2018
Bending Machinery
Bending and Rolling machine (DAVI)
Material forming - 4 roller bending machine
CNC control
Capacity to bend material max. thickness 110 mm; Width 3100 mm
Side hydraulic supports 10 tons
Upper guide elevator 25 ton
dim: 7 mt
Conical Bending device & Air cooling system
Production year: 2018
Power-Bend T 2000 Tons Press Brake (Ermaksan)
General characteristic:
16200*2000 tons press brake
Throat depth 1250 mm
Table height 800 mm
Table width 560 mm
Working height 1000 mm
Maximum thickness bending capacity: 28 mm
Production year: 2023
Welding Machinery
Welding manipulator for automatic welding – SAW (EKOWELD)
Capacity up to 1,000A
Working horizontal length 6,000m; working vertical length 6,000mm
ESAB ARISTO 1000 SAW machine
Automatic dust blow system
Laser tracker and camera
Production year: 2018
Welding Rotators (EKOWELD)
Capacity : Working horizontal length 5,000m
Working vertical length 8,000mm
Maximum load 50 Tons
Synchronised to welding column boom system
Production year: 2018
2 units of Robotic Welding System with 11 synchronous axes (CLOOS - QiROX)
- X axis: 16000 mm
- Y axis: 3000 mm
- Z axis: 2000 mm
60% 600A with Synergic-Pulse Feature
Twin wire feeder
Automatic Tool Changer
Production year: 2023
Welding Rotators (EKOWELD)
2 Welding MIG MAG machines (Fronius), 2018
3 Welding MIG MAG machines (Fronius), 2019
2 TIG welding machines (Fronius), 2018
2 SMAW welding machines (Fronius), 2018
1 Plasma cutting machine (ESAB), 2019
1 Carbon gauging (ESAB), 2019
Processing Machinery
DMG Mori NTX-2000 Millturning
Max. workpiece diameter 670 mm
Max. workpiece length 1,538 mm
Max. bar capacity diameter 65 mm
Max. X-axis stroke 675 mm
Max. Y-axis stroke 300 mm
Max. Z-axis stroke 1,562 mm
Production year:2023
Vertical CNC lathe / karuselk (TOS Kuřim)
General characteristics: Table diameter 4,000 mm Max diameter of piece turning 5,000 mm
Working stroke 2,840 mm (axis Z)
WorkPiece Wieght 100tons
Control system SINUMERIC 840D
Included devices: angle plates; clamping tools; holding
clamps; machine vices; fixtures; clamping elements, chip conveyor
Production year: 2018
7 axis CNC milling machine (TOS Kuřim)
General characteristic: dimension of rotating table 2,400x2000mm x=3,000 mm, y=3,000 mm, z=2,000 mm table capacity 49 tons
Control system SINUMERIC 840D
Included devices: rotary table; 2 times of angle plate 1000x2000mm; general fixing tools, chip conveyor
VK-VO-VA head
Production year: 2017
FRFQ 200 (TOS Kuřim)
General characteristic: dimension of rotating table 2,000x6,000mm x=6,000 mm, y=2,800 mm, z=1,500 mm
Control system Sinumerik 840D SL
Automatic tool magazine
Straight milling head VA1
Angle milling head VP1
Production year: 2018
FERMAT WFT 13 R
General characteristic: x=5,000 mm, y=2,500 mm, z=2,000 mm
Control system Heidenhain 820
Included devices: Anglehead – Micro position
3D M Sensor Robot
ATC Robot - 90
Production year: 2019
CNC Vertical Milling Machine (Wele)
General characteristic: Strok 1,500x650x600 Table size: 1,650 x650, table capacity 1,500 kg 20 magazine
0.012 mm position accuracy X axis move: 1,500 mm, Y axis move: 650 mm Z axis move: 600 mm
Chip conveyor
Production year: 2018
Horizontal CNC lathe (Doosan Puma)
General characteristic: Table diameter 600 mm
Max diameter of piece turning 650 mm
Working length 3,200 mm
Control system SINUMERIC 840D
Included devices: angle plates; clamping tools; holding clamps; machine vices; fixtures; clamping elements; Atling bed support
Production year: 2018
Universal lathe (zmm)
Distance between centres 5,250mm
Centre height over
guideways 520
Max diameter over bed: 1,040
Spindle nose DIN55027
Carriage cross slide travel
590, top slide travel 300
Quill diameter: 145
Production year: 2012
Universal lathe
Overbed dimension 940mm
Cross slide 685mm
Quill diameter: 125mm
Distance between centres 4,000mm
Workpiece max dia. over bed guide ways 1,320mm
Over carriage 940
Main motor power 30kW
Cross slide travel 685
Production year: 2015
Universal lathe
Quill diameter: 105mm
Distance between
centres 3,000mm
Workpiece max dia. over bed guide ways 700mm
Main motor power 15kW
Production year: 1997
Surface Preparation and Coating Equipment
Sand Blasting Machine (Özmak Makina)
Role Tables: Entrance 12 m + Exit 12 m
Input Dimension: 3100 x 600 mm
Feed Speed: 1-6 m/min
Number of Turbines and Power: 12 x 11 kW
Dust Filter: 1600 m
3
, Capacity - 160 Bags
Total Power: 233 kW
Production year: 2022
Painting & Impregnation Box
Work temperature: 20 - 25 c
Lighting: 4 x 20 w - 60 group
Ceiling filtration type: din 24185 eu5
Exhaust fan air capacity: 50,000 m3/h
Exhaust fan power: 22 kw
Fresh air capacity: 54,000 m3/h
Floor type: concrete floor and car rails
Doors type: industrial roller type
Room body material & isolation: 50 mm
Production year: 2018
DryingOven(statorwindingdrying)
Temperature (max): 220ºc
Isolation: 160 mm (rock wool)
Heater type: natural gas
Temperature control: 2 point by pt 100
Chimney temperature control: 1 point by pt 100
Flexible temp. measure device: 3 piece with 5 mt.
Exhaust fan flow: 4,000 m3/h
Exhaust fan motor power: 1,5 kW
Door net dimension: 4,500*4,500 mm
Production year: 2018
